The Process

While 3D modeling my fly fishing rod and reel in SolidWorks, I focused on both functional accuracy and realistic detail. First, I gathered reference images and measurements to capture the rod’s taper and the reel’s key components. Then, I used parametric sketches and revolve features to shape the rod’s cylindrical geometry, ensuring the taper transitioned smoothly. For the reel, I created dimensioned extrusions for the frame and spool, carefully aligning the assembly to accommodate its rotating mechanisms. Finally, I added fillets and chamfers to model real-world contours and strengthen component edges, resulting in a fully articulated, detailed fly fishing setup
